Our years of experience, commitment to service and state-of-the-art CNC centerless equipment put us at the top of our industry. We provide in-feed and through-feed grinding, as well as high-volume production services with exceptionally close tolerances. Our services also include: diamond roll dressing, parts washing, laser sorting, and packaging — all at competitive prices, delivered on time — every time.
Production Equipment
Micron Centerless Grinders
2 - Micron Centerless Grinders Model MSL-600VI-CNC
9 - Micron Centerless Grinder Model MPC-600C-CNC
1 - Micron Centerless Grinder Model MD-600III4W
1 - Micron Centerless Grinder Model MD-600V
Cincinnati Centerless Grinders
13 - #2 Centerless Grinders
1 - 350-20 RK Centerless Grinders
2 - 220-8 RK Centerless Grinder
Included in the above centerless equipment is:
7 - Centerless equipped with CNC capability
4 - Centerless equipped with diamond roll dressing capability
2 - Durr Ecoclean Parts Washer
1 - Cogsdill Roller Burnishing Machine 1-3"
1 - Ransohoff Parts Washer
1 - Roll Washer Unit K05314
Tool Room Equipment
Bridgeport Milling Machine
Lathe (LeBlond 15" Swing)
Brown & Sharp Surface Grinder (618 Micro Master)
Equipment for Welding, Brazing, etc.
Complete machine rebuilding equipment with all necessary inspection equipment for rebuilding centerless grinders.
Quality Control Equipment
6 sets of Ceramic Gage Blocks (81 piece English)
Tesa Profile 30 Inspection Instrument
2 - J & L 14" Optical Comparators
Aven AVE005-SPZV-50 Microscope with Camera HD & Monitor 11.6”
Mitutoyo Roundtest RA-114
Mahr Federal MMQ-200 Roundness Gage
Surfometer - Surface Measuring Gage
1 - Digital Readout
1 - Indicator Readout
67 Mechanical Gages with .000050" scale increments
TOLERANCES + CAPACITIES
Through-feed Grinding
Minimum thru-feed diameter: .125 inches
Maximum thru-feed diameter: 4.00 inches (100mm)
Maximum thru feed length: 24.00 inches (600mm)
Volume: 1 piece to 20,000 pieces
Material hardness: Up to Rc65
Materials accepted: Aluminum, Brass, Steel and Stainless
In-feed Grinding
Minimum in-feed diameter: .020 inch (.5mm)
Maximum in-feed diameter: 4.00 inch (100mm)
Maximum in-feed length: 6.00 inch (150mm)
Volume: 1 piece to 20,000 pieces
Material hardness: Up to Rc65
Materials accepted: Aluminum, Brass, Steel and Stainless
